With the last version of ETABS (2019)
First of all we will show the newest features in ETABS v19
Part 1,2,3: learn structural design of R.C Tower 52 stories from A to Z included all structural element (columns, beams, slabs, foundations, shear walls, earthquake and wind design, check deflection) using different earthquake systems (Shear wall system, moment frame system, and dual system)
Part 4 :we will use in this course viscous damper and show the benefit of using them and how we can model them into ETABS
Also we will learn in this course what is outrigger and how we can define and modeling it into ETABS V19 and we will show the benefits of using outrigger in high rise building
Part 5: show the effect of sub-modulus parameters (foundation type, and bearing capacity of soil) on the structural response of Tall buildings (story displacement, story drift, foundation settlement, and column forces)
-
7
Prepare DXF file to export it to ETABS -
8
Define number of stories and elevations
-
9
Draw columns, shear walls, slabs, opening and beams
-
10
Define materials
-
11
Define sections
-
12
Draw beams
-
13
Assign pier labels and mesh
-
14
Replicate
-
15
Define and draw retaining walls
-
16
Divide walls
-
17
Define fixed support
-
18
Define loads for the Tower
-
19
Assign loads on the Tower
-
20
Define mass source
-
21
Define modal cases
-
22
Define dynamic loads Function and loads cases
-
23
Define loads combinations
-
24
Define Diaphragms
-
25
Assign Diaphragms
-
26
Check the model
-
27
Define non sway frame
-
28
Release the frames
-
29
Define stiffness modifier
-
30
Compare static and dynamic loads
-
31
Check story displacement and story drift without using outrigger
-
32
Design Columns
-
33
Define and modeling the outrigger
-
34
Results with the outrigger
-
35
Design shear walls
